Drilling capacity: Φ32mm
Max. boring diameter: Φ50mm
Face milling capacity: Φ63mm
End milling capacity: Φ20mm
Distance from spindle nose to table: 450mm
Min.distance from spindle axis to column: 260mm
Spindle travel: 130mm
Spindle taper: MT3, MT4 or R8
Step of spindle speed: 6 steps
Range of spindle speed 50Hz: 80-1250 rpm
60Hz: 95-1500 rpm
Swivel angle of headstock (vertical): ±90°
Table size: 800x240mm (Optional 900×240mm )
Forward and backward travel of table: 175mm
Left and right travel of table: 500mm
Motor power: 1.5KW (2HP)
Net weight/gross weight: 320/370kg
Packing size: 770×880×1160mm
