Direct access to our certified experts
Hydraulic oil: Silicon Oil
Indicating way: 7 Inch Touch screen display
System sealing performance: Pressure drop < 10%FS within 1 minute
The Diameter of upper Platen hole mm: 31.5±0.05
The Diameter of Lower Platen hole mm: 31.5±0.05
The resistance of rubber diaphram Kpa: When raise 10mm,170-220, When raise 18mm,250-350
The tension between two platen Kpa: 100-1200 (Adjustable, With a voltage stabilization function, it ensures stable clamping force)
Testing Range Kpa: 250-5600
Testing Accuracy: Within ± 0.5 % of Indication value for F.S
Resolution Kpa: 0.01
Oil ml/min: 170±15
Weight: 55kgs
Power Supply: 220V, 50Hz, 1 pH
Standard Configuration: Main Machine, power line, special spanner, 3 Pcs Membrane for replacement, 2 rolls printer paper
Optional Configuration: Air Compressor
