Width: 102 mm (4.016 in)
Height: 43 mm (1.693 in)
Length: 214 mm (8.425 in)
Industry: Industrial
Approvals: EN60950-1, IEC60950-1, TUV, UL60950-1
Compliance: EN60950-1, IEC60950-1, TUV, UL60950-1
Efficiency: 89 %
Output Power: 603 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 400 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 50 A
Output Voltage-Channel 1: 12 VDC
Operating Temperature Range: - 40 C to + 85 C
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
