Width: 76.2 mm (3 in)
Height: 33 mm (1.299 in)
Length: 127 mm (5 in)
Industry: Industrial
Approvals: ANSI/AAMI, CSA/cUL, EN60601-1, EN60950-1, ES60601-1, UL60950-1
Compliance: ANSI/AAMI, CSA/cUL, EN60601-1, EN60950-1, ES60601-1, UL60950-1
Efficiency: 87 %
Output Power: 175 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 13.9 A
Output Voltage-Channel 1: 12 VDC
Operating Temperature Range: 0 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
