Width: 45 mm (1.772 in)
Height: 23 mm (0.906 in)
Length: 65.02 mm (2.56 in)
Industry: Medical
Approvals: CSA/cUL, CU15-M, EN60950, UL1950, UL2601-1
Compliance: CSA/cUL, CU15-M, EN60950, UL1950, UL2601-1
Efficiency: 65 %
Unit Weight: 60 g
Output Power: 8.25 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 2.5 A
Output Voltage-Channel 1: 3.3 VDC
Operating Temperature Range: 0 C to + 65 C
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: 0 C
