Width: 30.7 mm (1.209 in)
Height: 20 mm (0.787 in)
Length: 62 mm (2.441 in)
Industry: Industrial
Approvals: CSA/cUL, EN60950-1, IEC60950-1, UL60950-1
Compliance: CSA/cUL, EN60950-1, IEC60950-1, UL60950-1
Efficiency: 81 %
Unit Weight: 40 g
Output Power: 15 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: PCB
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 3 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 2 A
Output Current-Channel 2: 150 mA
Output Current-Channel 3: 150 mA
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 15 VDC
Output Voltage-Channel 3: - 15 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
