Width: 76.2 mm (3 in)
Height: 33 mm (1.299 in)
Length: 127 mm (5 in)
Industry: Medical, Industrial
Approvals: ANSI/AAMI, CSA/cUL, EN60601-1, EN60950-1, UL60950-1
Compliance: ANSI/AAMI, CSA/cUL, EN60601-1, EN60950-1, UL60950-1
Dimensions: 17 mm
Efficiency: 88 %
Unit Weight: 320 g
Output Power: 120 W
Input Voltage: 80 VAC to 264 VAC
Mounting Style: Panel
Input Frequency: 47 Hz to 400 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 3 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 5 A
Output Current-Channel 2: 500 mA
Output Current-Channel 3: 500 mA
Output Voltage-Channel 1: 24 VDC
Output Voltage-Channel 2: 12 VDC
Output Voltage-Channel 3: 5 VDC
Operating Temperature Range: - 40 C to + 85 C
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
