Width: 101.6 mm (4 in)
Height: 63.5 mm (2.5 in)
Length: 233.2 mm (9.181 in)
Industry: Medical
Approvals: ANSI/AAMI, CSA, EN, IEC, TUV
Compliance: ANSI/AAMI, CSA, EN, IEC, TUV
Efficiency: 85 %
Output Power: 655 W
Input Voltage: 80 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 18 A
Output Voltage-Channel 1: 36 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
