Width: 76.2 mm (3 in)
Height: 31.5 mm (1.24 in)
Length: 127 mm (5 in)
Industry: Industrial
Approvals: EN, IEC, UL
Compliance: EN, IEC, UL
Efficiency: 92 %
Output Power: 150 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Power - Convection: 100 W
Power - Forced Air: 150 W
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 3.13 A
Output Voltage-Channel 1: 48 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 10 C
