Width: 6.50 mm
Height: 2.30 mm
Length: 9.43 mm
Fall Time: 8 ns
Rise Time: 13 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: N-Channel
Qg - Gate Charge: 30 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 13 ns
Typical Turn-Off Delay Time: 33 ns
Id - Continuous Drain Current: 13.3 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 6.7 S
Rds On - Drain-Source Resistance: 290 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 5 V
