Width: 6.55 mm
Height: 2.25 mm
Length: 11.05 mm
Fall Time: 14 ns
Rise Time: 86 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 21 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 60 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 9.5 ns
Typical Turn-Off Delay Time: 24 ns
Id - Continuous Drain Current: 75 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 55 S
Rds On - Drain-Source Resistance: 6 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 3 V
