Circulation method: Forced air circulation
Operating temperature range: RT +15 to 210°C
Temp. control accuracy: ±0.5°C (at 210°C) JTM K05
Temp. distribution accuracy: ±2.0°C (at 210°C) JTM K05
Max. temp. reaching time: Approx. 60 min
Interior/Exterior material: Stainless steel /Electro-galvanized steel sheet with epoxy and melamine resin baking finish
Insulation material: Glass wool
Heater: Stainless pipe heater 1.5 kW×2
Fan type / Motor: Scirocco fan / Condenser type motor
Cable port: 33mm I.D. (the right, upper) 1pc.
Air in-take port: 33mm I.D. (the right, lower) 1pc.
Exhaust port: 33mm I.D.×2 (the back)
Temp. controller: PlD control by microprocessor
Internal dimensions (W×D×H): 1,090×500×1,000 mm
External dimensions (W×D×H): 1,220 ×695×1,660 mm
Internal capacity: 540L
Power supply: AC 220V Single-phase 15A
Weight: 185 kg
Accessories:
- Shelf plate: Stainless steel, 8 pcs
- Shelf bracket: 16 pcs. (2 pairs are fixed)
