Sensitivity (±10%): 25 mV/g
Measuring Range: ±50 g pk
Overload Limit (Shock): ±1,000 g pk
Resolution: 2 mg rms
Excitation Voltage: ±5 VDC
Excitation Current: ±5 VDC
DC offset: ±5 VDC
Frequency Range (±10%): 1 ~ 8 kHz
Frequency Range (−3dB): 0.5 ~ 10 kHz
Resonant Frequency: 30 kHz
Temperature Range: −40 ~ +85 °C
Sensing Element: Ceramic/Shear
Output Connector: 4 Conductors Cable
Housing Material: Hard Aluminum Oxide
Housing Isolation: ≥10⁸ Ω
Sealing: Epoxy Glue
Weight: 37 g
Size: Φ24×45 mm
Mounting: M5 (With Probe)
