Sensitivity: 630 μA/mm/s
Measuring Range (mm/s pk): ±12.7
Frequency Range (±10%): 5 ~ 1000 Hz
Resolution: 0.1 mm/s rms
Weight: 125 g
Size: Φ22×55 mm
Common parameters:
Power Supply: +15 ~ +30V DC
Non-linearity:＜3% F.S
Transverse Sensitivity:＜5%
Temperture Range:–40 ~ +85℃
Load Resistance:((VDC–15)x1000/20mA)Ω
Signal Ground Insulation Resistance: ≥10^8Ω
Output types:
4 ~ 20mA Output: 2 pin MIL–C–5015;
Terminal or lead output type: directly lead to the output signal;
Output with or initial acceleration signal:3 pin MIL–C–5015
