Control Method: Touch screen control + print output
Outer Box Dimensions: 115 × 65 × 125 cm
Box Volume: ≥ 0.5 cubic meters, with glass observation door
Flame Application Time: 0–99 minutes and 99 seconds can be set, with an accuracy of ±0.1 seconds
Residual Flame Time: 0–99 minutes and 99 seconds can be set, with an accuracy of ±0.1 seconds
Yu Zhuo Time: 0–99 minutes and 99 seconds can be set, with an accuracy of ±0.1 seconds
Experimental Combustion Gas: More than 98% methane / 37 MJ/m³ natural gas (coal gas is also acceptable)
Burner Size Parameters: Using imported lamps, the inner diameter of the nozzle is 9.5 ± 0.3 mm, and the effective length of the nozzle is 100 ± 10 mm
Flame Height: According to standard requirements, it can be adjusted from 20 mm to 175 mm
Flow Meter: Adopting the standard of 105 ml/min
Gas Leak Detection: Gas alarm device (optional)
Power Supply: AC 220V, 50Hz
