Measurement Range: 200 – 5600 kPa
Accuracy: ≤ ±0.5%
Resolution: 0.01 kPa
Deformation Error: ≤ 1 mm
Concentricity of Upper and Lower Plates: ≤ 0.25 mm
Adhesive Film Convex Disc Pressure: At 10 mm: 170 – 220 kPa; at 18 mm: 250 – 350 kPa
Oil Delivery Speed: 175 ± 5 ml/min
Pressure Plate Diameter: Upper disc diameter: 31.5 ± 0.5 mm; lower disc diameter: 31.5 ± 0.5 mm
Human–Machine Interface: 3.2-inch LCD display, real-time display of test data
Clamping Force: Greater than 690 kPa (adjustable)
Unit Conversion: kg/cm², kPa, lbf/in²
Print Output: Modular integrated thermal printer
Working Environment: Temperature (20 ± 10) ℃; humidity ≤ 85%
Overall Dimensions: 400 × 400 × 500 mm
Weight: 45 kg
