Simultaneous playback tracks: 2
Simultaneous recording tracks: 2
Functions: Lo-cut Filter, Limiter,Test Tone,Slate-Tone,Voice Emphasize
Filter, Playback Position Skipping, Playback Speed Control, A-B Repeat, Auto REC Level, Marker, Auto-Record, Pre-Record, Self-Timer, Overdubbing
Recording formats: WAV: 44.1 kHz/16-bit, 48 kHz/16-bit, 48 kHz/24-bit, 96 kHz/24-bit
A/D conversion: 24-bit, 128x oversampling
D/A conversion: 24-bit, 128x oversampling
Signal processing: 32-bit
Recording media: microSD/microSDHC cards (Class 4 or higher, up to 32 GB
Display: 1.25" monochrome LCD (96 × 64)
Built-in stereo mic: Unidirectional condenser, 90° XY stereo format
Gain: -∞ dB to +39 dB
Maximum sound pressure level: 120 dB SPL
Inputs: 1/8" stereo phone jack
Rated input level: -∞ dB to -39 dBm
Input impedance: 2 kΩ
Plug-in power supported (2.5 V)
Built-in speaker: Built-in 500 mW mono speaker
Output impedance: 8 Ω
Outputs: 1/8" stereo phone jack (combined line/headphones)
Rated output level: 20 mW + 20 mW into 32Ω load
Output impedance: 10 kΩ or more
microUSB: Connector: USB2.0 Micro-B
Card reader: USB 2.0 High Speed
Audio interface: USB 1.1 Full Speed / Specifications: 44.1/48kHz sampling rate, 16-bit depth, 2-in/2-out (USB class compliant) / Transfer method: asynchronous
Supported cable: USB2.0 Micro-B cable / * Use cables for data transfer. Cables for battery-charging cannot be used for the above purpose.
Supported OS Windows: Windows 8 / 8.1 / 10 / 11, Mac: Mac OS X 10.10 ~ macOS 15
Power requirements: 2 AAA batteries (alkaline, nickel-metal hydride rechargeable, or lithium)
AC adapter (ZOOM AD-17): DC 5V/1A
USB bus power
Battery life (alkaline batteries): Approximately 10 hours (continuous recording time using built-in mic, 44.1 kHz/16-bit)
Dimensions: 1.9 in (W) x 5.4 in (D) x 1.2 in (H) 50 mm (W) × 137.5 mm (D) × 32 mm (H)
Weight: 0.13 lbs / 60 g (without batteries)
