Performance Parameter
Gas: Measuring range | Resolution | Repeatability | Linearity | Response time | Drift
NH3: 0-20mg/m3 | 0.01mg/m3 | ≤1%FS | ≤1%FS | ≤10S | ≤±1%FS
HCL: 0-100mg/m3 | 0.1mg/m3 | ≤1%FS | ≤1%FS | ≤10S | ≤±1%FS
HF: 0-10mg/m3 | 0.01mg/m3 | ≤1%FS | ≤1%FS | ≤10S | ≤±1%FS
Functional Parameters
Preheat : 30min
Power Supply : AC100-240V/47-63Hz 3KW
Digital output : RS232/485/4-20mA
Environmental Parameters
Measuring Optical path: 5-10m
Sample gas temperature: ≤ 800 ℃
Sample gas pressure : Atmospheric pressure ±5kPa
Sampling flow : ≤3L/min
Ambient temperature: -30~55℃
Sampling method: In situ extraction
Size : 630（W）×230（L）×630（H）mm
Weight: 50kg
