Full Scale Flow Range: 250-500 slm
Measurement Range: 0.2-100 % Full Scale
Maximum Inlet Pressure: 150 psig
Burst Pressure: 1500 psig
Typical Accuracy: ±1% of Reading (with N2 calibration gas)
Repeatability: ±0.5% of Reading
Resolution: 0.1% of Full Scale
Zero Temperature Coefficient: <0.05% of Full Scale/°C
Span Temperature Coefficient: <0.08% of Reading/°C
Inlet Pressure Coefficient: <0.03% of Reading/psi
Warm-up Time: 1 hour
Operating Temperature: 10-50°C
Storage Humidity: 0 to 95% relative humidity, non-condensing
Storage Temperature: -20° to 65°C (-4° to 149° F)
Enclosure Rating: IP66
Power Requirements: 15-24 VDC @ (<4 watts)
Flow Input Output Signal: Voltage (0-5 VDC)
Current (4-20 mA)
Analog I/O Connector: 15 pin Type D male
Weight: <10.8 lbs (4.9 kg)
Compliance: CE
For specific range please check the attachment below!
