Scale: Direct Read
Accuracy: ± 5 %
Mounting: In-Line
Materials: Polycarbonate, PTFE
Scale Length: 127 mm
Air Flow, Max: 22 SCFM
Air Flow, Min: 2.2 SCFM
Valve Included: true
Number of Tubes: 1
Water Flow, Max: 4.1 GPM
Water Flow, Min: 0.41 GPM
Materials, Wetted: Borosilicate, PTFE
Scale Length Note: Scales: Rotatable, direct reading air (SCFM-SLPM) and water (GPM-LPM). Scale length is 127 mm (5") nominal
Media Compatibility: Air, Water
Mounting Orientation: In-Line
Additional Features 1: Dual Reading Scale
Leak Rate Under Vacuum: less than 10^⁻⁷ cc He/s
Operating Pressure, Max: 100 psi
Process Connection Size: 3/8 in
Process Connection Type: NPT Female
Process Temperature, Max: 65 °C
