Table Travel (X DM/SM): 400 mm
Table Travel (Y): 300 mm
Servo Travel (Z): 180 mm
Servo Travel (Z2): 250 mm
Max. Workpiece Dimensions (WxD): 945 x 510 mm
Max. Filling Height of Dielectric Tank: 215 mm
Distance Between Chuck to Table: 20 - 450 mm
Max. Workpiece Weight: 550 kg
Max. Electrode Weight: 120 kg
Table Size (WxD): 650 x 350 mm
Machine Weight: 1200 kg
Generator
Max. Working Current: 60A
Overall Power Consumption:6KVA
Weight: 320kg
Dielectric
Tank Capacity:380 L
Filter Density:20μm
Filter Elements: 3 pc
