PHOENIX CONTACT 1883268 Plugs 3 Pos 5.08mm pitch Plug 20-18 AWG IDC
Manufacturer: PHOENIX CONTACT Model: 1883268 - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Pitch: 5.08 mm
Width: 16.06 mm
Height: 15 mm
Length: 33.8 mm
Unit Weight: 5.526 g
Current Rating: 10 A
Mounting Style: Cable Mounts
Voltage Rating: 630 V
Wire Gauge Max: 18 AWG
Wire Gauge Min: 20 AWG
Contact Plating: Tin
Contact Material: Copper
Housing Material: Polyamide (PA)
Connection Method: IDC/IDT
Termination Style: Crimp
Flammability Rating: UL 94 V-0
Number of Positions: 3 Position
