Characterized frequency range: 0.1 Hz to 100 MHz
3 dB bandwidth: 100 Hz to 80 MHz (measured in a 50 + 50 Ohm loop)
Transfer impedance into 50 Ω load: -6 dBΩ; 0.5 V/A
Transfer impedance into high Z: 1 V/A
Probe port impedance: 50 Ω
Droop rate: 0.02 %/µs
Rise time: < 8 ns Max.
RMS AC current: 3A
Max. pulse current: 600A
Current time product: 0.007 Ampere seconds
Max. core temperature: 80 °C
Aperture diameter: 15 mm
Outside diameter: 61 mm
Height: 30 mm
Weight: 320 g
Connector type: N female; comes supplied with a coaxial adapter to BNC-female
